10gb fiber to my barn? Why not…

Don’t ever start looking at ebay when you are a systems engineer. You quickly find yourself convincing yourself that your home network is inadequate and should be keeping up with the multi-national infrastructure you work with day to day.

Imaging your Barn is Tokyo, your house is San Francisco… you need that 10gb connection to withstand 41 thousand simultaneous phone calls and to stream 6 terabits of media per hour! Well yes, i needed it. The man cave has needs.

So I began my research into fiber optics which admittedly I was a little behind on.

Fiber Optics vs. Coaxial Cables - The Beacon

Plan your attack

  • How far is the barn from the house
  • What type of fiber can I use
  • Do my switches support fiber?
  • What is the maximum length fiber I can run?
  • What types of connections are needed at both ends?
  • How much is this going to cost me? Am I nuts?
  • How can I get this project past the wife?

11/20 Update

Well i was able to get things purchased and installed. Here are the details

My main switch that I need to connect to is an “Arista DCS-7050T 10GBASET”

This switch has 48 10Gbe ports and 4 x 40GB QSFP+ (nuts!)

So to get fiber connected to this switch I purchased an “Arista QSFP-40G-XSR4” which is the QSFP to supply 40GB uplinks to something

Arista QSFP-40G-XSR4

Next, I needed a switch to accept fiber connects in the other building (Barn)

I went with a Cisco WS-CS3750X-48P. This is a pretty nice 48 x 1 GB POE switch with 4 x 10GBE uplinks. Note that these use SFP+ connections.


Ok, keep going, you need a connector on this side as well. I went with a standard Cisco SFP-10G-SR V03

SFP-10G-SR V03

So, all the hardware is good, now let’s start looking at Fiber options. Wow, I spent many hours looking at what would work with these 2 sides. On the main Arista switch, I have that Arista QSFP-40G-XSR4 which uses a MTP fiber connector

MTP and QSFP connection

The MTP connector actually has 12 fiber strands. My Arista has 40GB uplinks so how do I get the 40gb to work with the 10GB uplinks on the Cisco POE switch?

Well you need to get this fanout cable.

HPE PremierFlex OM4 Fiber Optic

This will convert the 40Gb out to 4 x 10GB SFP connections

So that is it for the hardware. This will provide 4 x 10Gb fiber links out to my barn. Even though I will only be using 1 x 10Gb link for future growth, I have some capacity obviously 🙂

Finally, let’s get digging!

The distance between my house and barn is 120 ft or so. So the cable I purchased was 50m which coverts to 165 ft.

Now more research….

  • How to get the fiber in the ground?
  • How deep?
  • Do I use a conduit?
  • What tools do I need

I decided to just bury the HP Fiber cable 4-5 inches down directly in the lawn. Using an edging shovel like this.

Using this shovel, I just “Split” the lawn as deep as possible and pushed the fiber down to the bottom of the valley

Having to go under a walkway was also interesting.

Found an old pipe and hammered it underneath the sidewalk. Then just fished the fiber through.

Added some conduit at each end buried 6 inches or so.

Final run to barn!

Job Done

Vanagon Carpet install on the cheap

Wanted to pass this along to anyone who is interested. I recently picked up an 86 GL that was extremely scrubby, sorry PO. Kids, dogs, general mayhem must have been involved. I did my research on the different Sewfine, Gowesty, Busdepot kits but couldn’t bring myself to cough up 300+ beans.

Enter Lowes. Found this Mohawk 60x84in commercial area rug which seemed to be pretty close to original dimensions and color (denim in my case)

I pulled out the original carpet by removing front skid plate and wooden bench support.
Removed the 2 metal rails and filled the gaps with two layers of a black Tread Mat

When comparing old nasty to the new carpet I only needed to make one cut along the sliding door side. All other sides fit and had the edges seamed up.

I also cut out the square piece for the rear heater.

Installing was pretty straight forward, just lay down and push to each wall.

and the final product!!!! Total cost Rug = $34 Rubber = $12

Configure Cisco 7960 phones with Asterisk PBX

This article describe the process to configure a Cisco 7960 SIP phone with an Asterisk PBX system.


  • Asterisk PBX or similar
  • TFTP Server
  • Cicso 7960G or similar IP phone


Asterisk Server Config

  • Create new SIP extension
    • Under “Applications / Extensions” choose Add Extension
  • Choose “CHAN SIP Device”
  • Enter User Extension: 702 (or whatever extension you want)
  • Under Secret: choose a password with at least 2 numbers
  • Click Save and Apply
  • Go back into config and make sure the Deny and Permit are set correctly
    • Deny:
    • Permit: (or whatever matches your network)

Configure your TFTP server

  • I’m using Linux so just install a tftp-server by typing the following:
yum install tftp-server
  • the default install on Centos7 will have the tftp-server root directory under /var/lib/tftpboot
  • Put the following files in that directory


SIP000A8A344598.cnf  (Fill in your MAC address after the SIPXXX.cnf)

SEP000A8A344598.cnf.xml  (Fill in your MAC address after the SEPXXX.cnf)
